| QoS (Quality of Service) | &bull 802.1p CoS/DSCP priority
&bull 8 priority queues
&bull Priority Schedule Mode
- SP (Strict Priority)
- WRR (Weighted Round Robin)
&bull Queue Weight Config
&bull Bandwidth Control
- Port/Flow based Rating Limit
&bull Smoother Performance
&bull Storm Control
- Multiple Control Modes(kbps/ratio)
- Broadcast/Multicast/Unknown-Unicast Control |
|---|
| Funzionalità L2 e L2+ | &bull 16 IP Interfaces
- Support IPv4/IPv6 Interface
&bull Static Routing
- 32 IPv4/IPv6 Static Routes
&bull DHCP Server
&bull DHCP Relay
- DHCP Interface Relay
- DHCP VLAN Relay
&bull DHCP L2 Relay
&bull Static ARP
&bull Proxy ARP
&bull Gratuitous ARP
&bull Link Aggregation
- Static link aggregation
- 802.3ad LACP
- Up to 8 aggregation groups and up to 8 ports
per group
&bull Spanning Tree Protocol
- 802.1D STP
- 802.1w RSTP
- 802.1s MSTP
- STP Security: TC Protect, BPDU Filter/Protect,
Root Protect
&bull Loopback Detection
&bull Flow Control
- 802.3x Flow Control
&bull Mirroring
- Port Mirroring
- CPU Mirroring
- One-to-One
- Many-to-One
- Flow-Based
- Ingress/Egress/Both
&bull Device Link Detect Protocol (DLDP)
&bull 802.1ab LLDP/ LLDP-MED |
|---|
| VLAN | &bull VLAN Group
- Max. 4K VLAN Groups
&bull 802.1Q tag VLAN
&bull MAC VLAN: 12 Entries
&bull Protocol VLAN
&bull GVRP
&bull Voice VLAN |
|---|
| ACL (Access Control List) | &bull Support up to 230 entries
&bull Time-Range
- Time Slice
- Week Time-Range
- Absolute Time-Range
- Holiday
&bull Time-based ACL
&bull MAC ACL
- Source MAC
- Destination MAC
- VLAN ID
- User Priority
- Ether Type
&bull IP ACL
- Source IP
- Destination IP
- IP Protocol
- TCP Flag
- TCP/UDP Source Port
- TCP/UDP Destination Port
- DSCP/IP TOS
&bull IPv6 ACL
&bull Combined ACL
&bull Rule Operation
- Permit/Deny
&bull Policy Action
- Mirror
- Rate Limit
- Redirect
- QoS Remark
&bull ACL Rules Binding
- Port Binding
- VLAN Binding
&bull Actions for flows
- Mirror (to supported interface)
- Redirect (to supported interface)
- Rate Limit
- QoS Remark |
|---|
| Sicurezza | &bull AAA
&bull 802.1X
- Port based authentication
- MAC (Host) based authentication
- Authentication Method includes PAP/EAP-MD5
- MAB
- Guest VLAN
- Support Radius authentication and
accountability
&bull IP/IPv6-MAC Binding
- 512 Binding Entries
- DHCP Snooping
- DHCPv6 Snooping
- ARP Inspection
- ND Detection
&bull IP Source Guard
- 253 Entries
- Source IP+Source MAC
&bull IPv6 Source Guard
- 183 Entries
- Source IPv6 Address+Source MAC
&bull DoS Defend
&bull Static/Dynamic/Permanent Port Security
- Up to 64 MAC addresses per port
&bull Broadcast/Multicast/Unicast Storm Control
- kbps/ratio control mode
&bull Port Isolation
&bull Secure web management through HTTPS with
SSLv3/TLS 1.2
&bull Secure Command Line Interface (CLI)
management with SSHv1/SSHv2
&bull IP/Port/MAC based access control |
|---|
| IPv6 | &bull IPv6 Static Routing and ACL
&bull IPv6 Dual IPv4/IPv6
&bull IPv6 Interface
&bull Multicast Listener Discovery (MLD) Snooping
&bull IPv6 neighbor discovery (ND)
&bull Path maximum transmission unit (MTU) discovery
&bull Internet Control Message Protocol (ICMP)
version 6
&bull TCPv6/UDPv6
&bull IPv6 applications
- DHCPv6 Client
- Ping6
- Tracert6
- Telnet(v6)
- IPv6 SNMP
- IPv6 SSH
- IPv6 SSL
- Http/Https
- IPv6 TFTP |
|---|
| Caratteristiche avanzate | &bull Automatic Device Discovery
&bull Batch Configuration
&bull Batch Firmware Upgrading
&bull Intelligent Network Monitoring
&bull Abnormal Event Warnings
&bull Unified Configuration
&bull Reboot Schedule |
|---|
| MIBs | &bull MIB II (RFC1213)
&bull Bridge MIB (RFC1493)
&bull P/Q-Bridge MIB (RFC2674)
&bull Radius Accounting Client MIB (RFC2620)
&bull Radius Authentication Client MIB (RFC2618)
&bull Remote Ping, Traceroute MIB (RFC2925)
&bull Support TP-Link private MIBs
&bull RMON MIB(RFC1757, rmon 1,2,3,9) |
|---|
