| Standard e protocolli | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p |
|---|
| Interfaccia | 16 10/100/1000 Mbps RJ45 Ports
(Auto Negotiation/Auto MDI/MDIX)
2 Gigabit SFP Ports |
|---|
| Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100&Omega STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100&Omega STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100&Omega STP (maximum 100m)
1000BASE-X MMF, SMF |
|---|
| Numero ventole | 2 Fans |
|---|
| Physical security lock | Yes |
|---|
| Alimentazione | 100-240V AC, 50/60 Hz |
|---|
| Porte PoE+ | Standard: 802.3at/802.3af compliant
PoE+ Ports: 16 Ports
Power Supply: 192W |
|---|
| Dimensioni ( L x P x A ) | 17.3 × 7.1 × 1.7 in. (440 × 180 × 44 mm) |
|---|
| Tipo di montaggio | Rack Mountable |
|---|
| Max Power Consumption | 18.73 W (220/50Hz. no PD connected)
217.22 W (220/50Hz. with 192W PD connected) |
|---|
| Max Heat Dissipation | 63.89 BTU/h (no PD connected)
741.15 BTU/h (with 192W PD connected) |
|---|
