| QoS (Quality of Service) | &bull 8 priority queues
&bull 802.1p CoS/DSCP priority
&bull Queue scheduling
- SP (Strict Priority)
- WRR (Weighted Round Robin)
- SP+WRR
&bull Bandwidth Control
- Port/Flow based Rating Limiting
&bull Smoother Performance
&bull Action for Flows
- Mirror (to supported interface)
- Redirect (to supported interface)
- Rate Limit
- QoS Remark |
|---|
| Funzionalità L2 e L2+ | &bull Link Aggregation
- static link aggregation
- 802.3ad LACP
- Up to 8 aggregation groups, containing 8 ports per group
&bull Spanning Tree Protocol
- 802.1d STP
- 802.1w RSTP
- 802.1s MSTP
- STP Security: TC Protect, BPDU Filter, Root Protect
&bull Loopback Detection
- Port based
- VLAN based
&bull Flow Control
- 802.3x Flow Control
- HOL Blocking Prevention
&bull Mirroring
- Port Mirroring
- CPU Mirroring
- One-to-One
- Many-to-One
- Tx/Rx/Both |
|---|
| L2 Multicast | &bull IGMP Snooping
- IGMP v1/v2/v3 Snooping
- Fast Leave
- IGMP Snooping Querier
- IGMP Authentication
&bull IGMP Authentication
&bull MLD Snooping
- MLD v1/v2 Snooping
- Fast Leave
- MLD Snooping Querier
- Static Group Config
- Limited IP Multicast
&bull MVR
&bull Multicast Filtering: 256 profiles and 16 entries per profile |
|---|
| VLAN | &bull VLAN Group
- Max 4K VLAN Groups
&bull 802.1Q Tagged VLAN
&bull MAC VLAN: 7 Entries
&bull Protocol VLAN: Protocol Template 16, Protocol VLAN 16
&bull Private VLAN
&bull GVRP
&bull VLAN VPN (QinQ)
- Port-Based QinQ
- Selective QinQ
&bull Voice VLAN |
|---|
| ACL (Access Control List) | &bull Time-based ACL
&bull MAC ACL
- Source MAC
- Destination MAC
- VLAN ID
- User Priority
- Ether Type
&bull IP ACL
-Source IP
- Destination IP
- Fragment
- IP Protocol
- TCP Flag
- TCP/UDP Port
- DSCP/IP TOS
- User Priority
&bull Combined ACL
&bull Packet Content ACL
&bull IPv6 ACL
&bull Policy
- Mirroring
- Redirect
- Rate Limit
- QoS Remark
&bull ACL apply to Port/VLAN |
|---|
| Sicurezza | &bull IP-MAC-Port Binding
- 512 Entries
- DHCP Snooping
- ARP Inspection
- IPv4 Source Guard: 100 Entries
&bull IPv6-MAC-Port Binding
- 512 Entries
- DHCPv6 Snooping
- ND Detection
- IPv6 Source Guard: 100 Entries
&bull DoS Defend
&bull Static/Dynamic Port Security
- Up to 64 MAC addresses per port
&bull Broadcast/Multicast/Unicast Storm Control
- kbps/ratio control mode
&bull 802.1X
- Port base authentication
- Mac base authentication
- VLAN Assignment
- MAB
- Guest VLAN
- Support Radius authentication andaccountability
&bull AAA (including TACACS+)
&bull Port Isolation
&bull Secure web management through HTTPS with SSLv3/TLS 1.2
&bull Secure Command Line Interface (CLI) management with SSHv1/SSHv2
&bull IP/Port/MAC based access control |
|---|
| IPv6 | &bull IPv6 Dual IPv4/IPv6
&bull Multicast Listener Discovery (MLD) Snooping
&bull IPv6 ACL
&bull IPv6 Interface
&bull Static IPv6 Routing
&bull IPv6 neighbor discovery (ND)
&bull Path maximum transmission unit (MTU) discovery
&bull Internet Control Message Protocol (ICMP) version 6
&bull TCPv6/UDPv6
&bull IPv6 applications
- DHCPv6 Client
- Ping6
- Tracert6
- Telnet (v6)
- IPv6 SNMP
- IPv6 SSH
- IPv6 SSL
- Http/Https
- IPv6 TFTP |
|---|
| Caratteristiche L3 | &bull 16 IPv4/IPv6 Interfaces
&bull Static Routing
- 48 static routes
&bull Static ARP
- 128 Static Entries
&bull Proxy ARP
&bull Gratuitous ARP
&bull DHCP Server
&bull DHCP Relay
- DHCP Interface Relay
- DHCP VLAN Relay
&bull DHCP L2 Relay |
|---|
| Gestione | &bull Web-based GUI
&bull Command Line Interface (CLI) through the console port, telnet
&bull SNMP v1/v2c/v3
- Trap/Inform
- RMON (1,2,3,9 groups)
&bull SDM Template
&bull DHCP/BOOTP Client
&bull 802.1ab LLDP/LLDP-MED
&bull DHCP AutoInstall
&bull Dual Image, Dual Configuration
&bull CPU Monitoring
&bull Cable Diagnostics
&bull EEE
&bull Password Recovery
&bull SNTP
&bull System Log |
|---|
| Caratteristiche avanzate | &bull Support Omada Hardware Controller (OC200/OC300), Software Controller, Cloud-Based Controller
&bull Automatic Device Discovery
&bull Batch Configuration
&bull Batch Firmware Upgrading
&bull Intelligent Network Monitoring
&bull Abnormal Event Warnings
&bull Unified Configuration
&bull Reboot Schedule
&bull ZTP (Zero-Touch Provisioning)* |
|---|
| MIBs | &bull MIB II (RFC1213)
&bull Interface MIB (RFC2233)
&bull Ethernet Interface MIB (RFC1643)
&bull Bridge MIB (RFC1493)
&bull P/Q-Bridge MIB (RFC2674)
&bull RMON MIB (RFC2819)
&bull RMON2 MIB (RFC2021)
&bull Radius Accounting Client MIB (RFC2620)
&bull Radius Authentication Client MIB (RFC2618)
&bull Remote Ping, Traceroute MIB (RFC2925)
&bull Support TP-Link private MIB |
|---|
