| interfaccia | &bull 5× 10/100 Mbps RJ45 Ports (Ports 1&ndash 4 support 802.3af PoE)
&bull AUTO Negotiation
&bull AUTO MDI/MDIX |
|---|
| Media | &bull 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
&bull EIA/TIA-568 100&Omega STP (maximum 100m)
&bull 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
&bull EIA/TIA-568 100&Omega STP (maximum 100m) |
|---|
| Numero ventole | Fanless |
|---|
| Physical security lock | Yes |
|---|
| Alimentatore esterno | External Power Adapter (Output: 53.5 V DC / 0.81 A) |
|---|
| Packet Forwarding Rate | 0.744 Mpps |
|---|
| Porte PoE | &bull Standard: 802.3 af compliant
&bull PoE Ports: Ports 1&ndash 4
&bull Power Supply: 41 W |
|---|
| Tabella ARP | 2K |
|---|
| Jumbo frame | 2 KB |
|---|
| Capacità di switching | 1 Gbps |
|---|
| Dimensioni ( L x P x A ) | 3.9× 3.9× 1.0 in (100× 98× 25 mm) |
|---|
| Max Power Consumption | &bull 1.9 W (220 V / 50 Hz, no PD connected)
&bull 47 W (220 V / 50 Hz, with 41 W PD connected) |
|---|
| Max Heat Dissipation | &bull 6.48 BTU/h(no PD connected)
&bull 160.27 BTU/h(with 41 W PD connected) |
|---|
