| Interfaccia | &bull 9× 10/100 Mbps RJ45 Ports (8× 10/100 Mbps 802.3af/at PoE+ ports)
&bull AUTO Negotiation
&bull AUTO MDI/MDIX |
|---|
| Media | &bull 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
&bull EIA/TIA-568 100&Omega STP (maximum 100m)
&bull 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
&bull EIA/TIA-568 100&Omega STP (maximum 100m) |
|---|
| Numero ventole | Fanless |
|---|
| Physical security lock | Yes |
|---|
| Alimentatore esterno | External Power Adapter (Output: 53.5VDC / 1.31A) |
|---|
| Packet Forwarding Rate | 1.3392 Mpps |
|---|
| Porte PoE | &bull Standard: 802.3 af/at compliant
&bull PoE Ports: Ports 1&ndash 8
&bull Power Supply: 65 W |
|---|
| Tabella ARP | 2K |
|---|
| Jumbo frame | 2 KB |
|---|
| Capacità di switching | 1.8 Gbps |
|---|
| Dimensioni ( L x P x A ) | 6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm) |
|---|
| Max Power Consumption | &bull 3.6 (220/50 Hz. no PD connected)
&bull 77.08 (220/50 Hz. with 65 W PD connected) |
|---|
| Max Heat Dissipation | &bull 12.28 BTU/h (no PD connected)
&bull 262.84 BTU/h (with 65 W PD connected) |
|---|
