| Standard e protocolli | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af,
IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, IEEE 802.3at |
|---|
| Interfaccia | Five 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX |
|---|
| Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100&Omega STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100&Omega STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100&Omega STP (maximum 100m) |
|---|
| Numero ventole | Fanless |
|---|
| Alimentazione | External Power Adapter (Output: 53.5 VDC/1.31 A) |
|---|
| Porte PoE | Standard: 802.3 af/at compliant
PoE Ports: Port 1- Port 4
PoE Power Budget: 65 W |
|---|
| Dimensioni ( L x P x A ) | 3.9 × 3.9 × 1.0 in (99.8 × 98 × 25 mm) |
|---|
| Max Power Consumption | 4.52 W (220V/50Hz with no PD connected)
75.16 W (220V/50Hz with 65 W PD connected) |
|---|
| Max Heat Dissipation | 15.41 BTU/h (with no PD connected)
256.30 BTU/h (with 65 W PD connected) |
|---|
